Switching DSA on
To reactivate the equalizer,

press and hold the

AUDIO button

for longer than two seconds.

The display shows the DSA menu.

Press the softkey

5 with the display

label "USER EQ".

Select an equalizer setting.

Automatically calibrating the
equalizer

You can perform and save electronic cali-
brations for three different situations (not
possible if crossover is set), e.g.:

EQ 1

For the driver alone

EQ 2

For the driver and front passenger

EQ 3

For the front and rear occupants

Hold the microphone in the appropriate po-
sition while the calibration is taking place.

The position of the calibration microphone
for Situation 1 (e.g. for the driver alone) is
at the height of the driver’s head, approx.
10 centimetres next to the right ear.

For Situation 2, the calibration microphone
should be positioned at head height be-
tween the driver and the front passenger.

For Situation 3, you should position the
calibration microphone at head height in
the centre of the vehicle interior (left/right,
front/rear).

Really quiet surroundings are required for
the calibration. Any extraneous noise will
distort the measured values. lose all win-
dows, doors, and the sliding sunroof during
the calibration. You should be sitting in the
driver's seat.

Note:
The sound radiating from the loud-
speakers must not be obstructed by
any objects. All the loudspeakers must
be connected. The calibration micro-
phone must be connected to the de-
vice, the calibration of the equalizer
should be performed before the DNC
calibration.

To calibrate an equalizer,

press and hold the

AUDIO button

for longer than two seconds.

Press the softkey

5 with the display

label "USER EQ".

Press the softkey

5 with the display

label of the equalizer ("EQ-1", "EQ-2"
or "EQ-3") to be calibrated.

Press the softkey

5 with the display

label "ADJUST".

Press the softkey

5 with the display

label "AUTO ADJ".

A countdown is running on the display. Dur-
ing this time, you can position the calibra-
tion microphone. After the countdown ex-
pires, the calibration is performed.

Use the same procedure for all equal-
izers.

After the calibration is complete, the menu
of the selected equalizer is displayed
again.

DSC Max – Equalizer
