Physical data, 581b ,c – Bryant 581C024--060 User Manual
Page 9
9
Table 1—Physical Data 581B
BASE UNIT 581B
036
048
060
072
NOMINAL CAPACITY (tons)
3
4
5
6
OPERATING WEIGHT (lb)
Unit
530
540
560
635
Perfect Humidity™ Adaptive Dehumidification System
15
23
25
29
EconoMi$er IV
50
50
50
50
Roof Curb
115
115
115
115
COMPRESSOR
Scroll
Quantity
1
1
1
1
Oil (oz)
42
53
50
60
REFRIGERANT TYPE
R-22
Expansion Device
Acutrol™ Metering Device
Operating Charge (lb-oz)
Standard Unit
5-8
10-2
10-0
12- 8
Unit With Perfect Humidity Adaptive Dehumidification System
12-5
18-8
20-5
23-14
CONDENSER FAN
Propeller
Quantity...Diameter (in.)
1...22
1...22
1...22
1...22
Nominal Cfm
3500
3500
4100
4100
Motor Hp...Rpm
1
/
4
...825
1
/
4
...825
1
/
4
...1100
1
/
4
...1100
Watts Input (Total)
180
180
320
320
CONDENSER COIL
3/8---in. OD Enhanced Copper Tubes, Aluminum Lanced Fins
Rows...Fins/in.
1...17
2...17
2...17
2...17
Total Face Area (sq ft)
14.6
16.5
16.5
21.3
EVAPORATOR COIL
3/8---in. OD Enhanced Copper Tubes, Aluminum Double-Wavy Fins
Standard Unit
Rows...Fins/in.
2...15
2...15
4...15
4...15
Total Face Area (sq ft)
5.5
5.5
5.5
7.3
Unit with Perfect Humidity Adaptive Dehumidification System
Rows...Fins/in.
1...17
2...17
2...17
2...17
Total Face Area (sq ft)
3.9
3.9
3.9
5.2
EVAPORATOR FAN
Centrifugal Type, Belt Drive
Quantity...Size (in.)
1...10 x 10
1...10 x 10
1...10 x 10
1...10 x 10
Nominal Cfm
1200
1600
2000
2400
Maximum Continuous Bhp
Std
1.20
1.20
1.30/2.40*
2.40
Hi-Static
2.40
2.40
2.90
2.90
Motor RPM
Std
1620
1620
1725
1725
Hi-Static
1725
1725
1725
1725
Motor Frame Size
Std
48
48
48/56*
56
Hi-Static
56
56
56
56
Fan Rpm Range
Std
680-1044
770-1185
1035-1460
1119-1585
Hi-Static
1075-1455
1075-1455
1300-1685
1300-1685
Motor Bearing Type
Ball
Ball
Ball
Ball
Maximum Fan Rpm
2100
2100
2100
2100
Motor Pulley Pitch Diameter A/B (in.)
Std
1.9/2.9
1.9/2.0
2.4/3.4
2.4/3.4
Motor Pulley Pitch Diameter A/B (in.)
Hi-Static
2.8/3.8
2.8/3.8
3.4/4.4
3.4/3.4
Nominal Motor Shaft Diameter (in.)
Std
1/2
1
/
2
5
/
8
5
/
8
Hi-Static
5
/
8
5
/
8
5
/
8
7
/
8
Fan Pulley Pitch Diameter (in.)
Std
4.5
4.0
4.0
4.0
Hi-Static
4.5
4.0
4.5
4.5
Belt — Type...Length (in.)
Std
1...A...36
1...A...36
1....4...40
1...A...38
Hi-Static
1...A...39
1...A...39
1...A...40
1...A...40
Pulley Center Line Distance (in.)
10.0-12.4
10.0-12.4
14.7-15.5
14.7-15.5
Speed Change per Full Turn of
Std
65
70
75
95
Speed Change per Full Turn of
Movable Pulley Flange (rpm)
Hi-Static
65
65
60
60
Movable Pulley Maximum Full
Std
5
5
6
5
Movable Pulley Maximum Full
Turns from Closed Position
Hi-Static
6
6
5
5
Factory Setting — Full Turns Open
Std
3
3
3
3
Hi-Static
3
1
/
2
3
1
/
2
3
1
/
2
3
1
/
2
Factory Speed Setting (rpm)
Std
826
936
1248
1305
Hi-Static
1233
1233
1396
1396
Fan Shaft Diameter at Pulley (in.)
5
/
8
5
/
8
5
/
8
5
/
8
LEGEND
Bhp — Brake Horsepower
581B
,C
