Page 3
3
ROOF CURB
ACCESSORY
A
UNIT
SIZE
CRRFCURB001A01
1 -2
[356]
CRRFCURB002A01
2 -0
[610]
NOTES:
1. Roof curb accessory is shipped disassembled.
2. Insulated panels.
3. Dimensions in [ ] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest
on curb).
6. Service clearance: 4 ft on each side.
7.
Direction of airflow.
8. Connector
packages
CRBTMPWR001A01
and 002A01 are for thru-the-curb type gas.
Packages CRBTMPWR003A01 and 004A01
are for thru-the-bottom type gas connections.
CONNECTOR
PKG. ACCY.
B
C
D ALT
DRAIN
HOLE
GAS
POWER
CONTROL ACCESSORY
POWER
CRBTMPWR001A01
1 -9
11
/
16
[551]
1 -4
[406]
1
3
/
4
[44.5]
3
/
4
[19] NPT
3
/
4
[19] NPT
1
/
2
[12.7]
1
/
2
[12.7]
CRBTMPWR002A01
1
1
/
4
[31.7]
CRBTMPWR003A01
1
/
2
[12.7] NPT
3
/
4
[19] NPT
CRBTMPWR004A01
3
/
4
[19] NPT
1
1
/
4
[31.7]
581B036-072
581C024-060
C06345
Fig. 2
--- Roof Curb Details
581B
,C
