Broilmaster BRB-1 - Manual (Page 12)

Page 12 B101502-1-0311
BBa t
anK
c
aDDy
e
XPlODeD
v
iew anD
P
arts
l
ist
1
2
3
VERIFY THAT ALL PARTS LISTED IN THE EXPLODED VIEW ON THIS PAGE HAVE BEEN INCLUDED IN
THIS BUILT-IN KIT BEFORE BEGINNING THIS INSTALLATION.
CAUTION: USE CAUTION WHEN HANDLING PARTS, AS THEY MAY CONTAIN SHARP EDGES.
WORK GLOVES ARE RECOMMENDED TO PREVENT INJURY.
PARTS LIST
Index No. Part No. Description Quantity
1 B101180 BBA Frame Assembly 1
2 B101181 BBA Door Assembly 1
3 B101022 8 x 3/4” Hex Head Screw 8
All repair part orders should be placed through your local Broilmaster ® dealer. To locate a dealer in your area,
contact Broilmaster ® Customer Service at 800-851-3153 • WWW.broilmaster.com. To ensure prompt and accurate
service, please provide the following information when placing a repair part order: Model number of your Single
Door, Part Name, Part Number, and Quantity of parts needed.
