User’s Manual
2-7
The Grand Tour
Battery release latch
Slide and hold this latch to release the battery
pack for removal.
For detailed information on removing the battery
packs, refer to Chapter 6,
Docking port
Use this port to connect an optional Slim Port
Replicator or High Capacity 2nd Battery Pack.
Keep foreign objects out of the docking port. Never allow metal objects,
such as screws, staples and paper clips, to enter the PC or keyboard.
Foreign metal objects can create a short circuit, which can cause PC
damage and fire, possibly resulting in serious injury.
Notches
Notches on the computer engage hooks on the
Slim Port Replicator or High Capacity 2nd battery
pack to hold the connection securely.
Memory module cover This cover protects one memory module socket
one or no module is preinstalled. Refer to the
Optional Devices.
Speaker
The internal monaural speaker emit sound
generated by your software as well as audio
alarms, generated by the system.
