User’s Manual 8-7
Optional Devices
Removing the memory module cover
4. Fit the memory module’s connectors into the socket at about a 45
degree angle and push the module down until latches on either side
snap into place.
Align the notch of the memory module with that of the memory slot and
gently insert the module into the slot.
Seating the memory module
Memory module cover
Screw
Align the grooves of the memory module with the locking tabs of the
connector and insert the module into the connector firmly. If you find it
difficult to install the memory module, try to adjust the tabs of the connector
with a pen tip or other tools. Make sure to hold the memory module with
your fingers on the side edges (sides with grooves).
■ Never allow metal objects, such as screws, staples and paper clips, to
enter the PC or keyboard. Foreign metal objects can create a short
circuit, which can cause PC damage and fire, possibly resulting in
serious injury.
■ Do not touch the connectors on the memory module or on the
computer. Debris on the connectors may cause memory access
problems.
