2-8 User’s Manual
The Grand Tour
Ultra Slim Bay See the Right side section in this chapter for
details.
Ultra Slim Bay latch Slide the latch to release or secure the Ultra Slim
Bay ejector.
Be sure to lock the Ultra Slim Bay latch before you transport or carry the
computer.
Ultra Slim Bay lock
screw One screw secures the Ultra Slim Bay latch.
Memory module
cover This cover protects memory module sockets.
Refer to the
Memory expansion section in
Chapter 8, Optional Devices .
HDD pack cover
screw One screw secures the HDD cover.
Hard disk drive This contains a Hard disk drive pack, which can
be removed and reinstalled. For more
information on how to remove or reinstall the
Hard disk drive pack , refer to Chapter 8, Optional
Devices .
