User’s Manual 2-3
The Grand Tour
Left side
The following figure shows the computer’s left side.
The left side of the computer
Display latch This latch secures the LCD panel in its closed
position. Slide the latch to open the display.
Infrared port This infrared port is compatible with Infrared Data
Association (IrDA 1.1) standards. It enables
cableless 4 Mbps, 1.15 Mbps, 115.2 kbps,
57.6 kbps, 38.4 kbps, 19.2 kbps or 9.6 kbps data
transfer with IrDA 1.1 compatible external
devices.
Microphone A built-in microphone lets you record sound into
your applications. Refer to the
Sound system
section in Chapter 4, Operating Basics .
Cooling vents
Security lock slot
PC card slot
SD card slot
PC card eject
button
LAN active indicator
(orange)
LAN jack
Link indicator (green)
ExpressCard slot
ExpressCard eject button
Video-out jack
External monitor port
Security lock slot A security cable attaches to this slot. The
optional security cable anchors your computer to
a desk or other large object to deter theft.
LAN jack This jack lets you connect to a LAN. The adaptor
has built-in support for Ethernet LAN
(10 megabits per second, 10BASE-T), Fast
Ethernet LAN (100 megabits per second,
100BASE-TX) and Gigabit Ethernet LAN
(1000 megabits per second, 1000BASE-T). The
LAN has two indicators. Refer to Chapter 4,
Operating Basics , for details.
■
Do not connect any cable other than a LAN cable to the LAN jack. It
could cause damage or malfunction.
■
Do not connect the LAN cable to a power supply. It could cause
damage or malfunction.
