User’s Manual
3-27
Hardware, Utilities and Options
USB FDD Kit
The USB floppy diskette drive accommodates either a 1.44 MB or 720 KB
floppy diskette and connects to one of the computer's USB ports.
The USB floppy diskette drive
Connecting the USB floppy diskette drive
To connect the drive, plug the floppy diskette drive’s USB connector into a
computer’s USB port.
Connecting the USB floppy diskette drive (PORTÉGÉ R600)
Eject button
Floppy
diskette slot
Disk-In-Use
Indicator
USB connector
Make sure the connector is properly aligned with the socket. Do not try to
force the connection, doing so can damage the connecting pins.
USB connector
USB port
If you connect the USB floppy diskette drive after the computer has
already been turned on, it will take about ten seconds for it to be
recognized by the computer. Do not attempt to disconnect and reconnect
the drive before this period has elapsed.
