Docking port This port enables connection of an optional
TOSHIBA Hi-Speed Port Replicator described in
chapter 3,
Hardware, Utilities and Options .
Some models are equipped with a Docking port.
Only the TOSHIBA Hi-Speed Port Replicator can be used with this
docking port.
Keep foreign objects out of the docking port. A pin or similar object
can damage the computer's circuitry. A plastic shutter protects the
connector.
Do not use the computer's External monitor port, when connecting the
TOSHIBA Hi-Speed Port Replicator to the computer.
Battery release latch Slide and hold this latch into its "Unlock" position
in order to release the battery pack for removal.
For more detailed information on removing the
battery pack please refer to chapter 6,
Power and
Power-Up Modes .
Memory module slot The memory module slot allows for the
installation, replacement and removal of
additional memory module.
Refer to the
Additional memory module section in
chapter 3, Hardware, Utilities and Options.
Front with the display open
This section shows the computer with the display panel open. In order to
open the display, lift the display panel up and position it at a comfortable
viewing angle for you.
PORTÉGÉ R700 / Satellite R630
User's Manual 2-7
