Additional information 10
46
En
Resetting the main unit
Use this procedure to reset all the receiver’s
settings to the factory default. Use the front
panel controls to do this.
1 Switch the receiver into standby.
2 While holding down the BAND button,
press and hold the  STANDBY/ON button
for about two seconds.
3 When you see RESET? appear in the
display, press the ‘AUTO SURROUND/
STREAM DIRECT’ button.
OK? shows in the display.
4 Press ‘STEREO/A.L.C.’ to confirm.
OK appears in the display to indicate that the
receiver has been reset to the factory default
settings.
Specifications
Audio section
Rated power output
Front, Center, Surround
. . . . . . . . .130 W per channel (1 kHz, 6
Ω, 1 %)
. . . . . . . . . . . . . . . . . . . . . . . 100 W per channel
(20 Hz to 20 kHz, 8 Ω, 0.09 %)
Total Harmonic Distortion
. . . . . . 0.06 % (20 Hz to 20 kHz, 8 Ω, 95 W/ch)
Frequency response (LINE Pure Direct mode)
. . . . . . . . . . . . . . . . . . . . 5 Hz to 100 kHz dB
Guaranteed speaker impedance . . . 6 Ω to 16 Ω
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 k
Ω
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . 200 mV/330 Ω
ZONE 2 . . . . . . . . . . . . . . . . . . . . . 200 mV/1 k
Ω
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 dB
Video Section
Signal level
Composite . . . . . . . . . . . . . . . . . . 1 Vp-p (75
Ω
)
Component Video . . . . . . . . Y: 1.0 Vp-p (75
Ω
)
PB, PR: 0.7 Vp-p (75
Ω
)
Corresponding maximum resolution
Component Video . . . . . . . . . . . 1080p (1125p)
Tuner Section
FM Frequency Range . . . . 87.5 MHz to 108 MHz
Antenna Input . . . . . . . . . . . . . 75
Ω unbalanced
AM Frequency Range . . . . . 531 kHz to 1602 kHz
Antenna . . . . . . . . . . . . . . . . . . . . . Loop antenna
Digital I/O
HDMI terminal . . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . 5 V, 100 mA
Integrated control section
Control (IR) terminal . . . ∅ 3.5 Mini-jack (MONO)
IR signal . . . . . . . High Active (High Level : 2.0 V)
