Connecting Up 01
6
En
Chapter 1
Connecting Up
Part names
1 WIRELESS IN L/R jacks
2 DC IN inlet
3 AC IN inlet
4 OUT L/R jacks (For use with VSX-D514)
5 SURROUND INPUT
(For use with VSX-D514)
WIRELESS
2 1
R IN L
Transmitter
3
Wireless speaker
TO TRANSMITTER
L R
OUT
MIN MAX
AUDIO LEVEL
L R
SURROUND INPUT
5 4
Signal converter
