Installation
En 16
English
Espa
ñ
ol
Deutsch
Fran
ç
ais
Italiano
Nederlands
17
Installation with the rubber bush Removing the unit
Frame
Pull out to remove the frame.
(When reattaching the frame, point
the side with a groove downwards
and attach it.)
Holder
After inserting the holder into the dash-
board, then select the appropriate tabs
according to the thickness of the dash-
board material and bend them.
(Install as firmly as possible using the top
and bottom tabs. To secure, bend the tabs
90 degrees.)
Rubber bush
Screw
Dashboard
1 182 1 182
53 53
Insert the supplied
extraction keys into the
unit, as shown in the
figure, until they click
into place. Keeping the
keys pressed against the
sides of the unit, pull the
unit out.
