Quick guide

initial auto installation

When the TV is powered on for the first time after

purchase, the initial auto installation wizard appears.

Follow the menus and make the necessary settings

one after another.

Press a on the TV.

The initial auto installation wizard appears.

Setting the OSD language.

English

Italiano

Svenska

Press a/b/c/d to select the desired language,

and then press

enter.

Setting the country (Location of the TV).

Austria A

B/G

Finland FIN B/G

Greece GR B/G

Press a/b/c/d to select your country or area,

and then press

enter.

This setting screen only appears during the first

installation.

Starting channel search.

Analogue Search

Digital Search

Press c/d to select “Digital Search” or

“Analogue Search”, and then press

enter.

If you want to search for more broadcasts, execute

“Additional Search” from the “Programme Setup”

menu (Pages 32 and 33).

To watch both analogue broadcasts and digital

broadcasts, you should perform the channel search

setting for each format.

eXample

If you execute “Digital Search” in the initial auto

installation wizard, you should perform “Analogue

Search” from “Auto Installation” under the “Setup”

menu.

1

2

3

4

The TV searches for, sorts and stores all the

receivable TV stations according to their settings

and the connected aerial.

To abort the initial auto installation in progress, press
6

(return).

note

If you turn off the power on the TV after performing step 4,

the initial auto installation wizard does not appear. The auto

installation function allows you to execute the installation

again from the “Setup” menu (Page 32).

The initial auto installation wizard will go off if you leave

the TV unattended for 30 minutes before searching for

channels in step 5.

Checking signal strength and

channel strength

If you install a DVB-T aerial for the first time or relocate

it, you should adjust the alignment of the aerial to

receive a good reception while checking the antenna

setup screen.

Press h and the “HOME MENU” screen

displays.
Press a/b to select “Setup”.
Press a/b to select “Antenna Setup-DIGITAL”,

and then press

enter.

Checking signal strength

Press a/b to select “Signal Strength”.

Signal Strength

Supply Voltage

Channel Strength

Signal Strength

Quality

Current

Max.

0

CH No.

21

0

Current

Max.

0

0

Checking channel strength

Press a/b to select “Channel Strength”, and

then press

enter.

You can input a specified frequency band using the

09 numeric buttons.

Signal Strength

Supply Voltage

Channel Strength

Signal Strength

Quality

Current

Max.

0

CH No.

21

0

Current

Max.

0

0

4 7 4

.

0

MHz

Position and align the aerial so that the

maximum possible values for “Signal Strength”

and “Quality” are obtained.

note

The values of “Signal Strength” and “Quality” indicate when

to check the appropriate alignment of the aerial.

5

1

2

3

E

E

4

Confirm the following before turning

on the power

Is the aerial cable connected?

Is the AC cord plugged in?

E
E
