Chapter 1 Before Use 1-14
1. 5. 6 “in use” Indicators
3 “in use” Indicators on the right front of KIP9000 are related with 3 drawers respectively, and
inform the operator which drawer must not be opened during printing.
One or two “in use” Indicator light orange when the KIP 9000 is on printing.
Do not open the drawer if the concerning “in use” Indicator is lighting orange.
The drawer can be opened even if the KIP9000 is on printing if the concerning “in use” Indicator is
not lighting.
Example : Top and middle drawer can not be opened as the “in use” Indicators for them are
lighting orange.
Only the bottom drawer can be opened as its “in use” Indicator is not lighting.
1
4
3
2
in use
1
4
3
2
in use
in use
in use
