Removal steps of LCD bezel assembly
1
1
1
1
Step Screw cap Screw (quantity) Color Torque
1 M2 × 4.5 mm, wafer-head, nylon-coated (4) Silver 0.392 Nm
(4 kgf-cm)
2
2
2
2
2
2
2
2
2
2
When installing: Make sure that all the latches are attached firmly. Then secure the bezel with the screws.
2020 LCD panel and hinges
For access, remove these FRUs in order:
•
“1010 Battery pack” on page 58
• “1020 Large bottom cover” on page 59
• “1030 Small bottom cover” on page 60
Chapter 9 . Removing or replacing a FRU 91
