• “1010 Battery pack” on page 58
• “1020 Large bottom cover” on page 59
Removal steps of optical drive or blank bezel
1
Note: Your models might look slightly different from the illustration above.
Step Screw (quantity) Color Torque
1 M2 × 3 mm, wafer-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
3
2
Note: Your models might look slightly different from the illustration above.
1050 Memory modules
For access, remove these FRUs in order:
•
“1010 Battery pack” on page 58
• “1020 Large bottom cover” on page 59
Chapter 9 . Removing or replacing a FRU 61
