Installing Cabling
14
Megabit Modem 410F and 420F User Manual
I
NSTALLING
C
ABLING
Install the cables:
•
the black cable for the 10/100BASE-T LAN connection
•
the grey phone cord for the ADSL port WAN connection
•
the power cable to the modem power connector then to the facility power outlet (cable
specified on
)
.
DSL
PO
W
ER
10BASE-T
RS-232
M
GMT
MD
I M
DI-X
10/100BASE-T port
RS-232 MGMT port
Megabit Modem 410F or 420F
PC, hub or other
network device
Wall jack with DMT ADSL
service
To power
outlet
ADSL port
Power
connector
