Rear panel connectors – Apple Power Macintosh 7100/80AV User Manual
Page 15
Basics
Rear Panel Connectors - 13
Rear Panel Connectors
The figure on the following page shows the rear panel of a
Power Macintosh 7100 computer with a 2 MB Video Card
installed. The AV version of the Power Macintosh 7100
would have a Power Macintosh AV Card installed instead of
the 2 MB Video Card. In addition to a DB-15 connector, the
AV Card includes an S-Video Input and an S-video Output
port.
