FIT-8-5
Nadir Air Exhaust Silencer
Dimensions in Inches (mm)
A
B
C
D
E
Model
Barrell
Overall
Dia
Thread
Flats
MF-14
1-15/32
1-15/16
1-1/4
1/4 NPT
1-5/32
MFT-38
1-15/32
1-15/16
1-1/4
3/8 NPT
1-5/32
MF-38
1-3/4
2-5/16
1-1/2
3/8 NPT
1-1/4
MFT-12
1-3/4
2-5/16
1-1/2
1/2 NPT
1-1/4
MF-12
1-7/8
2-5/8
1-3/4
1/2 NPT
1-1/2
MFT-34
1-7/8
2-5/8
1-3/4
3/4 NPT
1-1/2
MF-34
3-5/16
4-7/8
2-3/8
3/4 NPT
MFT-1
3-5/16
4-7/8
2-3/8
1 NPT
MF-100
4-3/8
6-1/2
3
1 NPT
MFT-114
4-3/8
6-1/2
3
1-1/4 NPT
MF-114
5-9/16
8-11/32
4
1-1/4 NPT
MFT-112
5-9/16
8-11/32
4
1-1/2 NPT
MF-112
6-1/2
9-7/8
4-1/2
1-1/2 NPT
MFT-200
6-1/2
9-7/8
4-1/2
2 NPT
● Meets all OSHA standards
● Machined from high tensile aluminum with no
plastics or castings
● Will pass particle contaminates to 100 microns
● Easily cleaned for longer service life
● Can withstand temperatures of 1000 degrees F
D
C
A
B
D
C
A
B
E
Dimensional Data
Dimensional Data
Technical Data
Maximum Pressure: 150 psi (10 bar)
Maximum temperature: 1000°F (538°C)
Materials
Aluminum and Sintered Bronze
Graphic Symbol
