VAL- 153
ISO Star Series Valves
5/2 and 5/3 solenoid and air pilot actuated valves
SXE 9574 – A70 – 0018 J B
Operator Type Substitute
Solenoid pilot operated valve SXE
Air pilot operated valve SXP
Connector Substitute
No electrical connector A
Cable grip B
6 ft molded cable, 0-240 V a.c./V d.c. C
6 ft molded cable, w/indicator light, surge suppression, 24V a.c./V d.c. 5
6 ft molded cable, 110-120 V a.c./V d.c.
6
Air pilot operated Left Blank
Connector Interface Substitute
22 mm coil with connector interface according
to Industrial Standard
J
22 mm coil with connector interface according
to DIN 43650 table “B”
L
30 mm coil with connector interface according
to DIN 43650 table “A”
N
No coil or air pilot operated Blank
Signal Duration Substitute
Momentary (2-position double operator only) 0
Continuous 9
Internal Variations Substitute
5-Port/2-position 5
5-Port/3-position, spring centered, all ports blocked 6
5-Port/3-position, spring centered, cylinder ports
open to exhaust
7
5-Port/3-position, spring centered, cylinder ports
open to pressure
8
Mounting Type Substitute
ISO Star Series 7
Size Substitute
Size 1 3
Size 2 4
Size 3 5
Solenoid Type Substitute
Standard solenoid pilot operator A
CNOMO solenoid pilot operator Z
Valve Body Options
Coils
Speed Control Substitute
double solenoid no 5
double solenoid yes 6
single solenoid no 7
single solenoid yes 8
Solenoid Voltage Substitute
12V d.c. 2
24V d.c. 3
24V 50/60 Hz 4
48V 50/60 Hz 6
110/120V 50/60 Hz 8
220/240V 50/60 Hz 9
No coil or air pilot operated Blank
Coil Substitute
20 mm coil 1
30 mm coil 2
Manual Override Substitute
Combination locking/nonlocking 00
Nonlocking 01
Low watt locking (CNOMO) 90
Pilot Supply/Integral Air Return Operator Substitute
Internal / integral air return 0
Internal / spring return 1
External / integral air 5
External / spring return 6
