Norgren ISO Star Series Valves - Manual (Page 2)

VAL- 147
ISO Star Series Valves
5/2 and 5/3 solenoid and air pilot actuated valves
Model Size Flow Pilot Operator Return Operating Pressure Pilot Pressure Weight
Control Supply psig (bar) psig (bar) lb. (kg)
SXE9573-A70-00***† #1 - Internal Solenoid Air Spring 14.5 - 145 (1 - 10) - 0.74 (0.33)
SXE9574-A70-00***† #2 - Internal Solenoid Air Spring 14.5 - 145 (1 - 10) - 1.34 (0.59)
SXE9575-A70-00***† #3 - Internal Solenoid Air Spring 14.5 - 145 (1 - 10) - 1.93 (0.85)
SXE9573-A80-00***† #1 Integral Internal Solenoid Air Spring 14.5 - 145 (1 - 10) - 0.74 (0.33)
SXE9574-A80-00***† #2 Integral Internal Solenoid Air Spring 14.5 - 145 (1 - 10) - 1.34 (0.59)
SXE9573-A75-00***† #1 - External Solenoid Air Spring 26" Hg - 232 (-0.9 - 16) 14.5 - 145 (1 - 10) 0.74 (0.33)
SXE9574-A75-00***† #2 - External Solenoid Air Spring 26" Hg - 232 (-0.9 - 16) 14.5 - 145 (1 - 10) 1.34 (0.59)
SXE9575-A75-00***† #3 - External Solenoid Air Spring 26" Hg - 232 (-0.9 - 16) 14.5 - 145 (1 - 10) 1.93 (0.85)
SXE9573-A85-00***† #1 Integral External Solenoid Air Spring 26" Hg - 232 (-0.9 - 16) 14.5 - 145 (1 - 10) 0.74 (0.33)
SXE9574-A85-00***† #2 Integral External Solenoid Air Spring 26" Hg - 232 (-0.9 - 16) 14.5 - 145 (1 - 10) 1.34 (0.59)
SXE0573-A50-00***† #1 - Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.02 (0.45)
SXE0574-A50-00***† #2 - Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.63 (0.72)
SXE0575-A50-00***† #3 - Internal Solenoid Solenoid 29 - 145 (2 - 10) - 2.18 (0.96)
SXE0573-A60-00***† #1 Integral Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.02 (0.45)
SXE0574-A60-00***† #2 Integral Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.63 (0.72)
SXE0573-A55-00***† #1 - External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.02 (0.45)
SXE0574-A55-00***† #2 - External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.63 (0.72)
SXE0575-A55-00***† #3 - External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 2.18 (0.96)
SXE0573-A65-00***† #1 Integral External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.02 (0.45)
SXE0574-A65-00***† #2 Integral External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.63 (0.72)
Model Size Flow Valve Pilot Operator Operator Operating Pressure Pilot Pressure Weight
Control Function* Supply psig (bar) psig (bar) lb. (kg)
SXE9673-A60-00***† #1 Integral APB Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.02 (0.45)
SXE9674-A60-00***† #2 Integral APB Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.63 (0.72)
SXE9675-A50-00***† #3 - APB Internal Solenoid Solenoid 29 - 145 (2 - 10) - 2.18 (0.96)
SXE9673-A65-00***† #1 Integral APB External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.02 (0.45)
SXE9674-A65-00***† #2 Integral APB External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.63 (0.72)
SXE9675-A55-00***† #3 - APB External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 2.18 (0.96)
SXE9773-A60-00***† #1 Integral COE Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.02 (0.45)
SXE9774-A60-00***† #2 Integral COE Internal Solenoid Solenoid 29 - 145 (2 - 10) - 1.63 (0.72)
SXE9775-A50-00***† #3 - COE Internal Solenoid Solenoid 29 - 145 (2 - 10) - 2.18 (0.96)
SXE9773-A65-00***† #1 Integral COE External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.02 (0.45)
SXE9774-A65-00***† #2 Integral COE External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.63 (0.72)
SXE9775-A55-00***† #3 - COE External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 2.18 (0.96)
SXE9873-A60-00***† #1 Integral COP Internal Solenoid Solenoid 29 - 14 5 (2 - 10) - 1.02 (0.45)
SXE9874-A60-00***† #2 Integral COP Internal Solenoid Solenoid 29 - 14 5 (2 - 10) - 1.63 (0.72)
SXE9875-A50-00***† #3 - COP Internal Solenoid Solenoid 29 - 14 5 (2 - 10) - 2.18 (0.96)
SXE9873-A65-00***† #1 Integral COP External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.02 (0.45)
SXE9874-A65-00***† #2 Integral COP External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 1.63 (0.72)
SXE9874-A65-00***† #3 - COP External Solenoid Solenoid 26" Hg - 232 (-0.9 - 16) 29 - 145 (2 - 10) 2.18 (0.96)
5/3 Solenoid Pilot Actuated Valves
5/2 Solenoid Pilot Actuated Valves
* Valve Function Designations: APB = All Ports Blocked
COE = Center Open Exhaust
COP = Center Open Pressure ***Insert 3-digit voltage code from Voltage Codes and Replacement Coils table below.
† Insert letter from Connector Option Codes.
Voltage Codes and Replacement Coils
Voltage 22 mm Coil 30 mm Coil
with connector interface with connector interface
acc. to Industrial Standard acc. to DIN 43650 table "A"
Code Power Inrush/Hold Coil Part.-no. Code Power Inrush/Hold Coil Part.-no.
12 V d.c. 12J 2 W 54469-01 22N 1.5 W V10633-A22N
24 V d.c. 13J 2 W 54469-02 23N 1.5 W V10633-A23N
24 V 50/60 Hz 14J 4/2.5 VA 54469-04 24N 3/2 VA V10633-A24N
48 V 50/60 Hz 16J 4/2.5 VA 54469-07 26N 3/2 VA V10633-A26N
110/120 V 50/60 Hz 18J 4/2.5 VA 54469-03 28N 3/2 VA V10633-A28N
220/240 V 50/60 Hz 19J 9/5.0 VA 54469-08 89N 10/8VA V10633-A89N
Other Voltages available on request.
Part Number Example
SXE9573-Z70-0012JA
Where “12J” is a 12V d.c. coil with a 22 mm connector interface, and “A” is a solenoid without connector.
