Norgren ISO Star Series Valves - Manual (Page 4)

VAL- 149
ISO Star Series Valves
5/2 and 5/3 solenoid and air pilot actuated valves
Model Size Flow Operator Return Operating Pressure Pilot Pressure Weight
Control psig (bar) psig (bar) lb. (kg)
SXP9573-170-00B #1 - Air Spring 26" Hg - 232 (-0.9 - 16) 23.2 - 232 (1.6 - 16) 0.47 (0.21)
SXP9574-170-00B #2 - Air Spring 26" Hg - 232 (-0.9 - 16) 23.2 - 232 (1.6 - 16) 1.02 (0.45)
SXP9575-170 #3 - Air Spring 26" Hg - 232 (-0.9 - 16) 23.2 - 232 (1.6 - 16) 1.63 (0.72)
SXP9573-180-00B #1 Integral Air Spring 26" Hg - 232 (-0.9 - 16) 23.2 - 232 (1.6 - 16) 0.47 (0.21)
SXP9574-180-00B #2 Integral Air Spring 26" Hg - 232 (-0.9 - 16) 23.2 - 232 (1.6 - 16) 1.02 (0.45)
SXP0573-170-00B #1 - Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 0.68 (0.30)
SXP0574-170-00B #2 - Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.13 (0.50)
SXP0575-170 #3 - Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.63 (0.72)
SXP0573-180-00B #1 Integral Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 0.68 (0.30)
SXP0574-180-00B #2 Integral Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.13 (0.50)
5/2 Air Pilot Actuated Valves
Model Size Flow Valve Operator Operator Operating Pressure Pilot Pressure Weight
Control Function* psig (bar) psig (bar) lb. (kg)
SXP9673-180-00B #1 Integral APB Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 0.57 (0.25)
SXP9674-180-00B #2 Integral APB Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.32 (0.58)
SXP9675-170 #3 - APB Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.82 (0.80)
SXP9773-180-00B #1 Integral COE Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 0.57 (0.25)
SXP9774-180-00B #2 Integral COE Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.32 (0.58)
SXP9775-170 #3 - COE Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.82 (0.80)
SXP9873-180-00B #1 Integral COP Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 0.57 (0.25)
SXP9874-180-00B #2 Integral COP Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.32 (0.58)
SXP9875-170 #3 - COP Air Air 26" Hg - 232 (-0.9 - 16) 29 - 232 (2 - 16) 1.82 (0.80)
5/3 Air Pilot Actuated Valves
* Valve Function Designations: APB = All Ports Blocked
COE = Center Open Exhaust
COP = Center Open Pressure
Voltage Codes and Replacement Coils
Voltage 22 mm Coil 30 mm Coil
with connector interface with connector interface
acc. to Industrial Standard acc. to DIN 43650 table "A"
Code Power Inrush/Hold Coil Part.-no. Code Power Inrush/Hold Coil Part.-no.
12 V d.c. 12J 2 W 54469-01 22N 1.5 W V10633-A22N
24 V d.c. 13J 2 W 54469-02 23N 1.5 W V10633-A23N
24 V 50/60 Hz 14J 4/2.5 VA 54469-04 24N 3/2 VA V10633-A24N
48 V 50/60 Hz 16J 4/2.5 VA 54469-07 26N 3/2 VA V10633-A26N
110/120 V 50/60 Hz 18J 4/2.5 VA 54469-03 28N 3/2 VA V10633-A28N
220/240 V 50/60 Hz 19J 9/5.0 VA 54469-08 89N 10/8VA V10633-A89N
Other Voltages available on request.
Part Number Example
SXE9573-Z70-0012JA
Where “12J” is a 12V d.c. coil with a 22 mm connector interface, and “A” is a solenoid without connector.
Connector option codes and replacement connectors
Other Connectors available on request.
Connector Option Codes 22 mm coil 30 mm coil
Industrial standard DIN 43650 table “A”
A = Solenoid without connector
B = Cable grip
54934-01 54933-05
C = 6 ft. molded cable, 0-240V a.c./V d.c. 54934-21 54933-06
5 = 6 ft. molded cable with indicator light surge suppression, 24V a.c./V d.c. 54934-30 54933-09
6 = 6 ft. molded cable with indicator light, 110V/50 Hz - 120V/60 Hz 54934-35 M/P43316/23
