Roundline Plus Stainless Steel Body Actuators
Norgren.com/usa – 303.794.2611 – [email protected]
Roundline Ecology Piston Seal Option (ERP)
The Ecology (Impact Dampening) Piston Seal option is available on select inch bore size Roundline cylinders in DAP, DAD, and DAN configurations. This
option includes non-adjustable air cushions on both the extend and retract stroke of the cylinder. By including the Ecology Piston Seal option, cylinders can
be specified based on weights of load being carried and speed of load. This is shown in the table below.
Energy Absorption Capacity of the Impact Dampening Piston Seal
This chart represents the energy absorption capacity of the Impact Dampening piston seals with standard Non-Adjustable air cushions. The values given
are usable pounds stoppable at stated piston speeds.
Cylinder Bore
In/Sec
3/4
1-1/16
1-1/4
1-1/2
2
2-1/2
6
36.6
62.3
74.5
115.5
258.9
421.1
12
5.6
15.6
18.6
28.9
64.7
105.3
18
2.5
6.9
8.3
12.8
28.8
46.8
24
1.4
3.9
4.7
7.2
16.2
26.3
30
0.9
2.5
3.0
4.6
10.4
16.8
36
0.6
1.7
2.1
3.2
7.2
11.7
42
0.5
1.3
1.5
2.4
5.3
8.6
48
0.3
1.0
1.2
1.8
4.0
6.6
54
0.3
0.8
0.9
1.4
3.2
5.2
60
0.2
0.6
0.7
1.2
2.6
4.2
Effect of Impact Dampening Seals on Total Stroke of Cylinders
Cylinder Bore
PSI
3/4
1-1/16
1-1/4
1-1/2
2
2-1/2
0
.11
.12
.12
.14
.15
.17
20
.08
.09
.09
.10
.10
.12
40
.05
.06
.06
.07
.07
.08
60
.03
.04
.04
.04
.04
.05
80
.01
.02
.02
.02
.02
.02
100
0
0
0
0
0
0
The figure above represents total stroke loss (both ends) for the pressure
indicated for new cylinders. The impact dampening seals will take some
compression set during operation of the cylinder and the stroke loss will
decrease. To determine stroke loss for either head or cap divide the value
shown by 2.
1
2
3
4
4
5
6
7
Oil impregnated sintered bronze Rod Bearing provides
exceptional rod support, and optimal cycle life
Chrome plated carbon steel Piston Rod for strength,
smooth operation, and long life (stainless steel Piston
Rod on 5/16, 7/16, 9/16 and all Double Rod cylinders)
Lip-Type nitrile Rod Seal, pressure energized and
wear compensating
Head and Cap are solid aluminum alloy for strength
and durability
Solid aluminum Piston is strong yet lightweight
for low inertia
Lip-type nitrile Piston Seals are wear compensating
for long life
304 stainless steel Cylinder Body with polished I.D.
ensures smooth performance and outstanding life cycle
Ecology Roundline Plus - ERP Model
IMPACT DAMPENING ECOLOGY PISTON SEALS
Increased load capabilities and cycle rates
Vibration and noise reduction
PRE-ENGINEERED NON-ADJUSTABLE CUSHION
Tamper resistant
Increased performance
»
»
»
»
»
»
»
»
The ERP model is the cost effective answer to load deceleration
and faster through cushion performance.
1
1
2
2
1
2
3
4
5
6
7
*Note: Single acting cylinders (not shown) use
springs manufactured from music wire to provide
millions of trouble free cycles.
