Roundline Plus Stainless Steel Body Actuators
Norgren.com/usa – 303.794.2611 – [email protected]
Dimensions in inches
Bore
A
C
D
E1
E2
EE
G
KK
MM
N1
RM
V
Y
Total Length
5/16"
0.38
N/A
N/A
0.61
0.36
10-32
0.31
5-40
0.125
3/8-24
.371/.373
0.03
0.47
1.49 + (1.25 per 1/2" of stroke)
7/16"
0.50
N/A
N/A
0.74
0.50
10-32
0.38
10-32
0.187
7/16-20
.434/.437
0.05
0.72
1.94 + (1.44 per 1/2" of stroke)
9/16"
0.50
N/A
N/A
0.62
0.62
10-32
0.38
10-32
0.187
7/16-20
.434/.437
0.06
0.75
2.00 + (2.62 per 1" of stroke)
3/4"
0.50
N/A
N/A
0.86
0.81
1/8 NPT
0.50
1/4-28
0.250
5/8-18
.621/.624
0.09
0.97
2.31 + (2.69 per 1" of stroke)
7/8"
0.50
N/A
N/A
0.94
0.94
1/8 NPT
0.50
1/4-28
0.250
5/8-18
.621/.624
0.09
0.97
2.31 + (2.56 per 1" of stroke)
1-1/16" 0.50
0.12
0.25
1.12
1.12
1/8 NPT
0.50
5/16-24
0.312
5/8-18
.621/.624
0.09
1.06
2.62 + (2.81 per 1" of stroke)
1-1/4" 0.75
0.25
0.38
1.34
1.34
1/8 NPT
0.63
7/16-20
0.437
3/4-16
.746/.749
0.09
1.37
3.47 + (2.81 per 1" of stroke)
1-1/2" 1.25
0.25
0.38
1.56
1.56
1/8 NPT
0.63
7/16-20
0.437
3/4-16
.746/.749
0.09
1.25
3.19 + (3.00 per 1" of stroke)
1-3/4" 0.88
0.31
0.44
1.84
1.84
1/4 NPT
0.75
1/2-20
0.500
1-14
1.029/1.032
0.09
1.62
4.03 + (3.00 per 1" of stroke)
2"
0.88
0.38
0.50
2.08
2.08
1/4 NPT
0.81
1/2-20
0.625
1-1/4-12 1.372/1.375
0.12
1.46
Consult Factory
Reverse Acting Spring Extend (RAN) — Nose Mount
Bore
A
C
CB
CD
E1
E2
EE
FL
G
KK
L
LH
M
MM (hex) N1
N2
RM
V
Total Length
7/16"
0.50
0.25 0.31 0.156 0.50 0.74 10-32
0.44 0.31 10-32
0.25 0.50 0.25
0.187
3/8-24
7/16-20 .369/.373
0.05
2.00 + (.94 per 1/2" of stroke)
9/16"* 0.50
0.25 0.31 0.156 0.62 0.62 10-32
0.38 0.38 10-32
0.25 N/A 0.19
0.187
7/16-20 7/16-20 .434/.437
0.06
2.06 + (1.62 per 1" of stroke)
3/4"
0.50
0.25 0.38 0.250 0.81 0.86 1/8 NPT 0.62 0.44 1/4-28
0.34 0.75 0.28
0.250
1/2-20
5/8-18
.494/.498
0.08
2.53 + (1.69 per 1" of stroke)
7/8"
0.50
0.25 0.38 0.250 0.94 0.94 1/8 NPT 0.62 0.50 1/4-28
0.34 0.75 0.28
0.250
5/8-18
5/8-18
.621/.624
0.09
2.72 + (1.56 per 1" of stroke)
1-1/16" 0.50
0.25 0.38 0.250 1.12 1.12 1/8 NPT 0.62 0.50 5/16-24 0.34 0.75 0.28
0.375
5/8-18
5/8-18
.621/.624
0.07
2.78 + (1.56 per 1" of stroke)
1-1/4" 0.88
0.25 0.50 0.250 1.34 1.34 1/8 NPT 0.78 0.63 7/16-20 0.41 0.88 0.40
0.437
3/4-16
3/4-16
.746/.749
0.09
3.38 + (1.81 per 1" of stroke)
1-1/2" 0.88
0.38 0.62 0.375 1.56 1.56 1/8 NPT 0.81 0.63 7/16-20 0.50 1.00 0.37
0.437
3/4-16
3/4-16
.746/.749
0.09
3.25 + (1.69 per 1" of stroke)
1-3/4" 0.88
0.38 0.62 0.375 1.84 1.84 1/4 NPT 1.12 0.74 1/2-20
0.50 N/A 0.50
0.500
1-14
1-14
1.029/1.032 0.09
4.09 + (2.00 per 1" of stroke)
Single Acting Non-Rotating (NRP) — Pivot Mount
* Pivot bushing included
