A-5
Intel ICH9M-E SATA RAID
3. In the Disks field, press the key and use key to select the
disks you want to create for the RAID volume. Then click key to finish
selection.
4. Then select the strip value for the RAID array by using the “upper arrow” or
“ down arrow” keys to scroll through the available values, and pressing the
key to select and advance to the next field.
5. Then select the capacity of the volume in the Capacity field. The default
value is the maximum volume capacity of the selected disks.
Important
Since you want to create two volumes (Intel Matrix RAID Technology), this
default size (maximum) needs to be reduced. Type in a new size for the first
volume. As an example: if you want the first volume to span the first half of the
two disks, re-type the size to be half of what is shown by default. The second
volume, when created, will automatically span the remainder of two hard
drives.
