MS-92B9 Server
1-4
v
Front I/O LEDs
LED Color State Description
Power/Sleep Green On Legacy power on/ACPI S0 state
Blink (~1/sec) Sleep/ACPI S1 state
Off Off Power off/ACPI S4, S5 state
HDD Activity Amber Random blink HDD accesss activity
Off Off No disk activity
RJ45 NIC 1 Linkage Green On LAN linked
/RJ45 NIC 2 Linkage Green Blinking LAN accessing
/RJ45 NIC 3 Linkage Off Off No LAN linked
RJ45 NIC 1 Access Amber On Gigabit mode access
/RJ45 NIC 2 Access Green On 100M mode access
/RJ45 NIC 3 Access Off Off 10M mode access
