Application Note
Design Guide for a CS1610 and CS1611
Dimmer-Compatible SSL Circuit
1 Overview of the CS1610/11
The CS1610 and CS1611 are digital control ICs engineered to deliver a high-efficiency, cost-effective, flicker-free,
phase-dimmable, solid-state lighting (SSL) solution for the incandescent lamp replacement market. The CS1610/11
is designed to control a quasi-resonant flyback topology. The CS1610 and CS1611 are designed for 120VAC and
230VAC line voltage applications, respectively.
The CS1610/11 integrates a critical conduction mode (CRM) boost converter that provides power factor correction
and dimmer compatibility with a constant output current, quasi-resonant second stage. An adaptive dimmer
compatibility algorithm controls the boost stage and dimmer compatibility operation mode to enable flicker-free
operation to 2% output current with leading-edge, trailing-edge, and digital dimmers (dimmers with an integrated
power supply).
1.1 Features
• Best-in-Class Dimmer Compatibility
- Leading-edge (TRIAC) Dimmers
- Trailing-edge Dimmers
- Digital Dimmers (with Integrated Power Supply)
• Up to 90% Efficiency
• Flicker-free Dimming
• 0% Minimum Dimming Level
• Quasi-resonant Second Stage with Constant-current Output
- Flyback for 1610/11
• Fast Startup
• Tight LED Current Regulation: Better than ±5%
• Primary-side Regulation (PSR)
• >0.9 Power Factor
• IEC-61000-3-2 Compliant
• Soft Start
• Protections:
- Output Open/Short
- Current-sense Resistor Open/Short
- External Overtemperature Using NTC
