CS5531/32/33/34-AS
6 DS289F5
ANALOG CHARACTERISTICS
(Continued)
(See Notes 1 and 2.)
8. All outputs unloaded. All input CMOS levels.
9. Power is specified when the instrumentation amplifier (Gain
≥ 2) is on. Analog supply current is reduced
by approximately 1/2 when the instrumentation amplifier is off (Gain = 1).
10. Tested with 100 mV change on VA+ or VA-.
Parameter Min Typ Max Unit
Power Supplies
DC Power Supply Currents (Normal Mode) I
A+,
I
A-
I
D+
-
-
6
0.6
8
1 mA
mA
Power Consumption Normal Mode (Notes 8 and 9)
Standby
Sleep
-
-
- 35
5
500
45
-
-
mW
mW
µW
Power Supply Rejection (Note 10)
dc Positive Supplies
dc Negative Supply -
- 115
115 -
- dB
dB
