CS5531/32/33/34-AS

20

DS289F5

PERFORM CONVERSION

Function:

These commands instruct the ADC to perform either a single, fully-settled conversion or con-
tinuous conversions on the physical input channel pointed to by the pointer bits (CSRP2 -
CRSP0) in the channel-setup register.

MC (Multiple Conversions)

0

Perform a single conversion.

1

Perform continuous conversions.

CSRP [2:0] (Channel Setup Register Pointer Bits)

000

Setup 1 (All devices)

001

Setup 2 (All devices)

010

Setup 3 (All devices)

011

Setup 4 (All devices)

100

Setup 5 (All devices)

101

Setup 6 (All devices)

110

Setup 7 (All devices)

111

Setup 8 (All devices)

D7(MSB)

D6

D5

D4

D3

D2

D1

D0

1

MC

CSRP2

CSRP1

CSRP0

0

0

0
