CS5531/32/33/34-AS

4

DS289F5

1. CHARACTERISTICS AND SPECIFICATIONS

ANALOG CHARACTERISTICS

(VA+, VD+ = 5 V ±5%; VREF+ = 5 V; VA-, VREF-, DGND = 0 V; MCLK = 4.9152 MHz;
OWR (Output Word Rate) = 60 Sps; Bipolar Mode; Gain = 32)
(See Notes 1 and 2.)

Notes: 1. Applies after system calibration at any temperature within -40 °C ~ +85 °C.

2. Specifications guaranteed by design, characterization, and/or test. LSB is 16 bits for the CS5531/33 and

LSB is 24 bits for the CS5532/34.

3. This specification applies to the device only and does not include any effects by external parasitic

thermocouples.

4. Drift over specified temperature range after calibration at power-up at 25 °C.

Parameter

CS5531/CS5533

Unit

Min

Typ

Max

Accuracy

Linearity Error

-

±0.0015

±0.003

%FS

No Missing Codes

16

-

-

Bits

Bipolar Offset

-

±1

±2

LSB

16

Unipolar Offset

-

±2

±4

LSB

16

Offset Drift

(Notes 3 and 4)

-

10

-

nV/°C

Bipolar Full-scale Error

-

±8

±31

ppm

Unipolar Full-scale Error

-

±16

±62

ppm

Full-scale Drift

(Note 4)

-

2

-

ppm/°C

Parameter

CS5532/CS5534

Unit

Min

Typ

Max

Accuracy

Linearity Error

-

±0.0015

±0.003

%FS

No Missing Codes

24

-

-

Bits

Bipolar Offset

-

±16

±32

LSB

24

Unipolar Offset

-

±32

±64

LSB

24

Offset Drift

(Notes 3 and 4)

-

10

-

nV/°C

Bipolar Full-scale Error

-

±8

±31

ppm

Unipolar Full-scale Error

-

±16

±62

ppm

Full-scale Drift

(Note 4)

-

2

-

ppm/°C
