CS5525 CS5526
6 DS202F5
SWITCHING CHARACTERISTICS
(T
A
= 25 °C; VA+ = 5 V ±5%; VD+ = 3.0 V ±10% or 5 V ±5%;
Input Levels: Logic 0 = 0 V, Logic 1 = VD+; C
L
= 50 pF.))
Notes: 19. Device parameters are specified with a 32.768 kHz clock; however, clocks up to 100 kHz can be used
for increased throughput.
20. Specified using 10% and 90% points on waveform of interest. Output loaded with 50 pF.
21. Oscillator start-up time varies with crystal parameters. This specification does not apply when using an
external clock source.
22. Applicable when SCLK is continuously running.
Parameter Symbol Min Typ Max Unit
Master Clock Frequency (Note 19)
Internal Clock
External Clock
XIN
30
30 32.768
32.768 36
100
kHz
Master Clock Duty Cycle 40 - 60 %
Rise Times (Note 20)
Any Digital Input Except SCLK
SCLK
Any Digital Output
t
rise
-
-
- -
-
50
1.0
100
-
µs
µs
ns
Fall Times (Note 20)
Any Digital Input Except SCLK
SCLK
Any Digital Output
t
fall
-
-
- -
-
50
1.0
100
-
µs
µs
ns
Start-up
Oscillator Start-up Time XTAL = 32.768 kHz (Note 21) t
ost
- 500 - ms
Power-on Reset Period t
por
- 1003 - XIN
cycles
Serial Port Timing
Serial Clock Frequency SCLK 0 - 2 MHz
SCLK Falling to CS Falling for continuous running SCLK
(Note 22)
t
0
100 - - ns
Serial Clock Pulse Width High
Pulse Width Low
t
1
t
2
250
250 -
- -
- ns
ns
SDI Write Timing
CS Enable to Valid Latch Clock t
3
50 - - ns
Data Set-up Time prior to SCLK rising t
4
50 - - ns
Data Hold Time After SCLK Rising t
5
100 - - ns
SCLK Falling Prior to CS Disable t
6
100 - - ns
SDO Read Timing
CS to Data Valid t
7
- - 150 ns
SCLK Falling to New Data Bit t
8
- - 150 ns
CS Rising to SDO Hi-Z t
9
- - 150 ns
