CS5525 CS5526
DS202F5 3
ANALOG CHARACTERISTICS
(Continued)
Notes: 9. The minimum Full-scale Calibration Range (FSCR) is limited by the maximum allowed gain register
value (with margin). The maximum FSCR is limited by the
∆Σ modulator’s 1’s density range.
10. The maximum full-scale signal can be limited by saturation of circuitry within the internal signal path.
11. All outputs unloaded. All input CMOS levels.
Parameter Min Typ Max Unit
Analog Input
Common Mode + Signal on AIN+ or AIN- Bipolar/Unipolar Mode
NBV = -1.8 to -2.5 V Range = 25 mV, 55 mV, or 100 mV
Range = 1 V, 2.5 V, or 5 V
NBV = AGND Range = 25 mV, 55 mV, or 100 mV
Range = 1 V, 2.5 V, or 5 V
-0.150
NBV
1.85
0.0
-
-
-
- 0.950
VA+
2.65
VA+
V
V
V
V
Common Mode Rejection dc
50, 60 Hz -
- 120
120 -
- dB
dB
Input Capacitance - 10 - pF
CVF Current on AIN+ or AIN- (Note 5)
Range = 25 mV, 55 mV, or 100 mV
Range = 1 V, 2.5 V, or 5 V -
- 100
1.2
300
-
pA
µA/V
System Calibration Specifications
Full-scale Calibration Range Bipolar/Unipolar Mode (Note 9)
25 mV
55 mV
100 mV
1 V
2.5 V
5 V 17.5
38.5
70
0.70
1.75
3.50
-
-
-
-
-
- 32.5
71.5
105
1.30
3.25
VA+
mV
mV
mV
V
V
V
Offset Calibration Range Bipolar/Unipolar Mode
25 mV
55 mV
100 mV
(Note 10)
1 V
2.5 V
5 V
-
-
-
-
-
- -
-
-
-
-
- ±12.5
±27.5
±50
±0.5
±1.25
±2.50
mV
mV
mV
V
V
V
Power Supplies
DC Power Supply Currents (Normal Mode) I
A+
I
D+
I
NBV
-
-
-
1.65
15
475
2.2
30
700
mA
µA
µA
Power Consumption Normal Mode (Note 11)
Low Power Mode
Standby
Sleep
-
-
-
- 9.4
4.9
1.2
500
12.7
8.5
-
-
mW
mW
mW
µW
Power Supply Rejection dc Positive Supplies
dc NBV -
- 95
110
-
- dB
dB
