CS5525 CS5526
DS202F5 5
DYNAMIC CHARACTERISTICS
RECOMMENDED OPERATING CONDITIONS
(AGND, DGND = 0 V; See Note 14.))
Notes: 14. All voltages with respect to ground.
ABSOLUTE MAXIMUM RATINGS
(AGND, DGND = 0 V; See Note 14.)
Notes: 15. No pin should go more negative than NBV - 0.3 V.
16. Applies to all pins including continuous overvoltage conditions at the analog input (AIN) pins.
17. Transient current of up to 100 mA will not cause SCR latch-up. Maximum input current for a power
supply pin is ±50 mA.
18. Total power dissipation, including all input currents and output currents.
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Parameter Symbol Ratio Unit
Modulator Sampling Frequency f
s
XIN/2 Hz
Filter Settling Time to 1/2 LSB (Full Scale Step) t
s
1/f
out
s
Parameter Symbol Min Typ Max Unit
DC Power Supplies Positive Digital
Positive Analog
VD+
VA+
2.7
4.75
5.0
5.0 5.25
5.25 V
V
Analog Reference Voltage (VREF+) - (VREF-) VRef
diff
1.0 2.5 3.0 V
Negative Bias Voltage NBV -1.8 -2.1 -2.5 V
Parameter Symbol Min Max Unit
DC Power Supplies (Note 15)
Positive Digital
Positive Analog
VD+
VA+
-0.3
-0.3 +6.0
+6.0 V
V
Negative Bias Voltage Negative Potential NBV +0.3 -3.0 V
Input Current, Any Pin Except Supplies (Note 16 and 17) I
IN
- ±10 mA
Output Current I
OUT
- ±25 mA
Power Dissipation (Note 18) PDN - 500 mW
Analog Input Voltage VREF pins
AIN Pins
V
INR
V
INA
-0.3
NBV - 0.3
(VA+) + 0.3
(VA+) + 0.3 V
V
Digital Input Voltage V
IND
-0.3 (VD+) + 0.3 V
Ambient Operating Temperature T
A
-40 85 °C
Storage Temperature T
stg
-65 150 °C
