CS5509
DS125F3 3
Notes: 8. All measurements are performed under static conditions.
9. I
out
= -100 µA. This guarantees the ability to drive one TTL load. (V
OH
= 2.4 V at I
out
= -40 µA).
Specifications are subject to change without notice
DYNAMIC CHARACTERISTICS
Parameter Symbol Ratio Unit
Modulator Sampling Frequency f
s
f
clk
/2 Hz
Output Update Rate (CONV = 1) f
out
f
clk
/1622 Hz
Filter Corner Frequency f
-3dB
f
clk
/1928 Hz
Settling Time to 1/2 LSB (FS Step) t
s
1/f
out
s
5V DIGITAL CHARACTERISTICS
(T
A
= 25 °C; VA+, VD+ = 5V ±5%; GND = 0) (Notes 2 and 8)
Parameter Symbol Min Typ Max Unit
High-level Input Voltage XIN
All Pins Except XIN V
IH
3.5
2.0 -
- -
- V
V
Low-level Input Voltage XIN
All Pins Except XIN V
IL
-
- -
- 1.5
0.8 V
V
High-level Output Voltage (Note 9) V
OH (VD+) -1.0 - - V
Low-level Output Voiltage I
out
= 1.6 mA V
OL - - 0.4 V
Input Leakage Current I
in - ±1 ±10 µA
3-State Leakage Current I
OZ
- - ±10 µA
Digital Output Pin Capacitance C
out - 9 - pF
3.3V DIGITAL CHARACTERISTICS
(T
A
= 25 °C; VA+ = 5V ±5%; VD+ = 3.3V ±5%; GND = 0)
(Notes 2 and 8)
Parameter Symbol Min Typ Max Unit
High-level Input Voltage XIN
All Pins Except XIN V
IH
0.7 VD+
0.6 VD+ -
- -
- V
V
Low-level Input Voltage XIN
All Pins Except XIN V
IL
-
- -
- 0.3 VD+
0.16 VD+
V
V
High-level Output Voltage (Note 9) V
OH
(VD+) -0.3 - - V
Low-level Output Voltage I
out
= 1.6 mA V
OL - - 0.3 V
Input Leakage Current I
in - ±1 ±10 µA
3-state Leakage Current I
OZ - - ±10 µA
Digital Output Pin Capacitance C
out
- 9 - pF
