Power Supply Section
Table 7 illustrates the power supply connections to the evaluation board. The +5 binding post (J3) supplies the pos-
itive analog supply (VA+) for the CS5466 and the +2.5 V reference. The VD+_EXT binding post (J5) supplies the
digital section of the CS5466 (VD+) and level shifters. Jumper J8 allows the VD+ supply to be sourced from the
VD+_EXT binding post (J5), the +5 V binding post (J3), or the regulated +3.3 V supply derived from the microcon-
troller. The Vu+_EXT (J6) binding post supplies the positive supply for the 8051 processor (8051_REGIN). Jumper
J9 allows the 8051_REGIN supply to be sourced from either the Vu+_EXT binding post (J6), +5 V binding post (J3)
or VD+_EXT binding post (J5).
Power Supplies
Power Post Connections
VD+
8051-REGIN
Analog (VA+) Digital (VD+) 8051 (Vu+)
+5V
GND
VD+EXT VU+EXT
J8
J9
+5
+5
+5
+5
0
NC
NC
+5
NC
+5
NC
+5
NC
+5
+3.3
+5
+5
0
NC
NC
+5
+3.3
NC
+5
Table 7. Power Supply Connections
