6 DS563F2
CS5381
ANALOG CHARACTERISTICS (CS5381-KSZ/-KZZ)
Test conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is
10 Hz to 20 kHz.
4. Referred to the typical full-scale input voltage.
5. Measured between AIN+ and AIN-.
Parameter Symbol Min Typ Max Unit
Single-Speed Mode Fs = 48 kHz
Dynamic Range A-weighted
unweighted
114
111
120
117
-
- dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
THD+N
-
-
- -110
-97
-57
-104
-
-
dB
dB
dB
Double-Speed Mode Fs = 96 kHz
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
114
111
-
120
117
114
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -110
-97
-57
-107
-104
-
-
-
dB
dB
dB
dB
Quad-Speed Mode Fs = 192 kHz
Dynamic Range A-weighted
unweighted
40 kHz bandwidth unweighted
114
111
-
120
117
114
-
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -110
-97
-57
-107
-104
-
-
-
dB
dB
dB
dB
Dynamic Performance for All Modes
Interchannel Isolation - 110 - dB
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Gain Error -5 - 5 %
Gain Drift -
±
100 - ppm/°C
Offset Error HPF enabled
HPF disabled
-
- 0
100
-
- LSB
LSB
Analog Input Characteristics
Full-scale Input Voltage 1.07*VA 1.13*VA 1.18*VA Vpp
Input Impedance (Differential) (Note 5) - 2.5 - k
Ω
Common Mode Rejection Ratio CMRR - 100 - dB
