Cirrus Logic CS5368 - Manual (Page 41)

DS624F5 41
CS5368
9. ORDERING INFORMATION
10.REVISION HISTORY
Product Description Package Pb-Free Grade Temp Range Container Order #
CS5368
114 dB, 192 kHz,
8-channel A/D
Converter
48-pin
LQFP
YES
Commercial -40°C to +85°C
Tray CS5368-CQZ
Tape & Reel CS5368-CQZR
Automotive -40°C to +105°C
Tray CS5368-DQZ
Tape & Reel CS5368-DQZR
CDB5368 Evaluation Board for CS5368 CDB5368
Revision Changes
F1
DEC ‘06
Initial release.
F2
JUL ‘07
Updated the wording of pin 24, LRCK/FS, in the pin description table on page 7 to correctly reflect the
high/low clocking state for odd-channel c in I²S and LJ Modes.
F3
JAN ‘08
Corrected SCL/CCLK pin description (Pin 39) for "Control Port Mode" on page 8 .
F4
APR ‘09
Corrected Absolute Max temp for “Ambient Operating Temperature (Power Applied)” on page 10 .
F5
JUL ‘14
Updated I
2
C and SPI bullet under “Additional Control Port Features” on page 1 .
Added Note 2 to “Switching Specifications - Control Port - I²C Timing” on page 17 .
