3. CHARACTERISTICS AND SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
GND = 0 V, all voltages with respect to 0 V.
1. TDM Quad-Speed Mode specified to operate correctly at VLS  3.14 V.
ABSOLUTE RATINGS
Operation beyond these limits may result in permanent damage to the device. Normal operation is not guaranteed
at these extremes. Transient currents up to ±100 mA on the analog input pins will not cause SCR latch-up.
SYSTEM CLOCKING
Parameter Symbol Min Typ Max Unit
DC Power Supplies: Positive Analog
Positive Crystal
Positive Digital
Positive Serial Logic
Positive Control Logic
VA
VX
VD
VLS
VLC
4.75
4.75
3.14
1.71 1
1.71
5.0
5.0
3.3
3.3
3.3
5.25 V
Ambient Operating Temperature (-CQZ)
(-DQZ) T
AC
T
AA
-40
-40 -
- 85
105
°C
Parameter Symbol Min Typ Max Units
DC Power Supplies: Positive Analog
Positive Crystal
Positive Digital
Positive Serial Logic
Positive Control Logic
VA
VX
VD
VLS
VLC
-0.3 - +6.0 V
Input Current I
in
-10
-
10 mA
Analog Input Voltage V
IN
-0.3
VA+0.3
V
Digital Input Voltage V
IND
VL+0.3
Ambient Operating Temperature (Power Applied) T
A
-50 +125
C
Storage Temperature T
stg
-65 +150
Parameter Symbol Min Typ Max Unit
Input Master Clock Frequency MCLK 0.512 55.05 MHz
Input Master Clock Duty Cycle t
clkhl
40 60 %
