DS624F5

35

CS5368

5.11 09h Reserved

5.12 0Ah (SDEN) SDOUT Enable Control Register

Default: 0x00, all SDOUT pins enabled.

The SDOUT Enable Control Register is used to tri-state the serial audio data output pins. Each bit, when
set, tri-states the associated SDOUT pin.

R/W

7

6

5

4

3

2

1

0

RESERVED

-

-

-

-

-

-

-

-

R/W

7

6

5

4

3

2

1

0

R/W

RESERVED

SDEN4

SDEN3

SDEN2

SDEN1
