DS624F5 11
CS5368
DC POWER
MCLK = 12.288 MHz; Master Mode; GND = 0 V.
1. Power-Down is defined as RST = LOW with all clocks and data lines held static at a valid logic level.
LOGIC LEVELS
PSRR, VQ AND FILT+ CHARACTERISTICS
MCLK = 12.288 MHz; Master Mode. Valid with the recommended capacitor values on FILT+ and VQ as shown in
the “Typical Connection Diagram”.
Parameter Symbol Min Typ Max Unit
Power Supply Current VA = 5 V
(Normal Operation) VX = 5 V
VD = 5 V
VD = 3.3 V
VLS, VLC = 5 V
VLS, VLC = 3.3 V
I
A
I
X
I
D
I
D
I
L
I
L
-
100
4
70
42
12
5
112
8
88
50
15
8
mA
Power Supply Current VA = VX = 5 V
(Power-Down) (Note 1) VLS, VLC, VD = 5 V
I
A
I
D+L
-
50
500
- A
Power Consumption
Normal Operation
All Supplies = 5 V
VA = VX = 5 V, VD = VLS = VLC = 3.3 V
(Power-Down) (Note 1)
- -
930
675
2.75
1115
792
-
mW
Parameter Symbol Min Typ Max Units
High-Level Input Voltage %VLS/VLC V
IH
70 - - %
Low-Level Input Voltage %VLS/VLC V
IL
- - 30 %
High-Level Output Voltage at 100 A load %VLS/VLC V
OH
85 - - %
Low-Level Output Voltage at -100 A load %VLS/VLC V
OL
- - 15 %
SDA Low-Level Output Voltage at -2 mA load %VLC V
OL
- - TBD %
OVFL Current Sink -4 mA
Input Leakage Current logic pins only I
in
-10 - 10 A
Parameter Symbol Min Typ Max Unit
Power Supply Rejection Ratio at (1 kHz) PSRR - 65 - dB
V
Q
Nominal Voltage
Output Impedance
Maximum allowable DC current source/sink -
VA/2
25
10 -
V
k 
A
Filt+ Nominal Voltage
Output Impedance
Maximum allowable DC current source/sink
-
VA
4.4
10
-
V
k 
A
