ANALOG CHARACTERISTICS - COMMERCIAL GRADE (-CZZ)
Test conditions (unless otherwise specified): T
A
= 25
C; Input test signal is a 997 Hz sine wave through recom-
mended inputs as seen in Figure 6 on page 14 ; source impedance less than or equal to 2.5 k
; valid with FILT+
and VQ components as shown in Figure 3 on page 11 ; measurement bandwidth is 10 Hz to 20 kHz; Fs = 48 kHz
or 96 kHz.
Notes:
4. Referred to the typical full-scale input voltage
Dynamic Performance for Commercial Grade VA = 3.3 V VA = 5.0 V
Symbol Min Typ Max Min Typ Max Unit
Dynamic Range A-weighted
unweighted
91
88 94
91 -
- 95
92 98
95 -
- dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
THD+N
-
-
- -89
-71
-31 -86
-
-
-
-
- -92
-75
-35 -89
-
-
dB
dB
dB
Dynamic Performance for Commercial Grade VA = 3.3 V and VA = 5.0 V
Min Typ Max Unit
Interchannel Isolation - 90 - dB
DC Accuracy
Interchannel Gain Mismatch - - 0.1 dB
Gain Error -3 - +3 %
Gain Drift -

100 - ppm/°C
Analog Input Characteristics
Full-scale Input Voltage VA = 3.3 V nom 0.560*VA 0.568*VA 0.575*VA Vpp
Full-scale Input Voltage VA = 5 V nom 0.552*VA 0.559*VA 0.567*VA Vpp
Input Impedance - 7.5 - M

