4 DS687F4
CS5343/4
Draft
2/1/11
2. CHARACTERISTICS AND SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
GND = 0 V, all voltages with respect to GND.
ABSOLUTE MAXIMUM RATINGS
GND = 0 V, all voltages with respect to GND. (Note 1)
Notes:
1. Operation beyond these limits may result in permanent damage to the device. Normal operation is not
guaranteed at these extremes.
2. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause
SCR latch-up.
3. The maximum over/under voltage is limited by the input current.
Parameter Symbol Min Typ Max Unit
Power Supplies
VA
3.1
4.75
3.3
5.0 3.5
5.25
V
V
Ambient Operating Temperature Commercial (-CZZ)
Automotive (-DZZ)
T
AC
T
AD
-40
-40 -
- 85
105
°C
°C
Parameter Symbol Min Max Unit
DC Power Supplies VA -0.3 +6.0 V
Input Current (Note 2) I
in
-10
10
mA
Input Voltage (Note 3) V
IN
-0.7 VA+0.7 V
Ambient Operating Temperature (Power Applied) T
A
-50 +115
C
Storage Temperature T
stg
-65 +150
C
