CS4299
19
4. REGISTER INTERFACE
Reg Register Name D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Default
00h Reset 0 SE4 SE3 SE2 SE1 SE0 0 ID8 ID7 0 0 ID4 0 0 0 0 1990h
02h Master Volume Mute 0 ML5 ML4 ML3 ML2 ML1 ML0 0 0 MR5 MR4 MR3 MR2 MR1 MR0 8000h
04h Alternate Volume Mute 0 ML5 ML4 ML3 ML2 ML1 ML0 0 0 MR5 MR4 MR3 MR2 MR1 MR0 8000h
06h Mono Volume Mute 0 0 0 0 0 0 0 0 0 MM5 MM4 MM3 MM2 MM1 MM0 8000h
0Ah PC_BEEP Volume Mute 0 0 0 0 0 0 0 0 0 0 PV3 PV2 PV1 PV0 0 0000h
0Ch Phone Volume Mute 0 0 0 0 0 0 0 0 0 0 GN4 GN3 GN2 GN1 GN0 8008h
0Eh Mic Volume Mute 0 0 0 0 0 0 0 0 20dB 0 GN4 GN3 GN2 GN1 GN0 8008h
10h Line In Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0 8808h
12h CD Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0 8808h
14h Video Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0 8808h
16h Aux Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0 8808h
18h PCM Out Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0 8808h
1Ah Record Select 0 0 0 0 0 SL2 SL1 SL0 0 0 0 0 0 SR2 SR1 SR0 0000h
1Ch Record Gain Mute 0 0 0 GL3 GL2 GL1 GL0 0 0 0 0 GR3 GR2 GR1 GR0 8000h
20h General Purpose 0 0 3D 0 0 0 MIX MS LPBK 0 0 0 0 0 0 0 0000h
22h 3D Control 0 0 0 0 0 0 0 0 0 0 0 0 S3 S2 S1 S0 0000h
26h Powerdown Ctrl/Stat EAPD PR6 PR5 PR4 PR3 PR2 PR1 PR0 0 0 0 0 REF ANL DAC ADC 000Fh
28h Extended Audio ID ID1 ID0 0 0 0 0 AMAP 0 0 0 0 0 0 0 0 VRA 0201h
2Ah Extended Audio Ctrl/Stat 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 VRA 0000h
2Ch PCM Front DAC Rate SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0 BB80h
32h PCM L/R ADC Rate SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0 BB80h
Cirrus Logic Defined Registers:
5E AC Mode Control 0 0 0 0 0 0 0 DDM AMAP 0 SM1 SM0 0 0 0 0 0080h
60 Misc. Crystal Control 0 0 0 0 Reserved 0 0 Reserved 0 Reserved LOSM 0023h
68 S/PDIF Control SPEN Val 0 Fs L CC6 CC5 CC4 CC3 CC2 CC1 CC0 Emph Copy /Audio Pro 0000h
7Ch Vendor ID1(CR) F7 F6 F5 F4 F3 F4 F1 F0 S7 S6 S5 S4 S3 S2 S1 S0 4352h
7Eh Vendor ID2(Y-) T7 T6 T5 T4 T3 T2 T1 T0 0 DID2 DID1 DID0 0 REV2 REV1 REV0 5931h
Table 1. Mixer Registers
DS319PP6 19
CS4299
