3.2.3
Status Data Port (Slot 2)
RD[15:0]
Read Data. The RD[15:0] bits contain the register data requested by the controller from the
previous read request. All read requests will return the read address in the input Slot 1 and
the register data in the input Slot 2 on the following serial data frame.
3.2.4
PCM Capture Data (Slot 3-10)
CD[17:0]
Capture Data. The D[17:0] bits contain 18-bit PCM (2’s complement) capture data. The map-
ping of a given slot to an ADC is determined by the state of the ID[1:0] bits in the Extended
Audio ID Register (Index 28h) and the SM[1:0] and AMAP bits in the AC Mode Control Reg-
ister (Index 5Eh). The definition of each slot can be found in Table 8 on page 30.
Bit 19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RD15 RD14 RD13 RD12 RD11 RD10 RD9 RD8 RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0
Reserved
Bit 19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
CD17 CD16 CD15 CD14 CD13 CD12 CD11 CD10 CD9 CD8 CD7 CD6 CD5 CD4 CD3 CD2 CD1 CD0
0
0
