DS686DB3 19
CDB4270
5.2 FPGA CODE REVISION ID - ADDRESS 00H
5.2.1 Revision Number Bits (Bits 7:0)
Function:
Identifies FPGA code revision number. REV.7 - REV.4 indicate revision whole number, and REV.3 -
REV.0 indicate revision decimal number. These register bits are Read-Only. See
Table 1 .
7 6 5 4 3 2 1 0
REV.7 REV.6 REV.5 REV.4 REV.3 REV.2 REV.1 REV.0
REV.7 REV.6 REV.5 REV.4 REV.3 REV.2 REV.1 REV.0 Revision Number
0 0 0 0 0 0 0 0 Not Used
0 0 0 1 0 0 0 1 Revision 1.1
0 0 0 1 0 0 1 0 Revision 1.2
0 0 0 1 0 0 1 1 Revision 1.3
0 0 0 1 0 1 0 0 Revision 1.4
0 0 0 1 0 1 0 1 Revision 1.5
0 0 0 1. 0 1 1 0 Revision 1.6
0 0 0 1 0 1 1 1 Revision 1.7
0 0 0 ... ... ... ... ... ...
0 0 0 1 1 1 1 1 Revision 1.15
... ... ... ... ... ... ... ... ...
1 1 1 1 1 0 0 1 Revision 15.9
1 1 1 1 1 0 1 0 Revision 15.10
1 1 1 1 1 0 1 1 Revision 15.11
1 1 1 1 1 1 0 0 Revision 15.12
1 1 1 1 1 1 0 1 Revision 15.13
1 1 1 1 1 1 1 0 Revision 15.14
1 1 1 1 1 1 1 1 Revision 15.15
Table 1. Revision Number
