6.5 Interface Formats (address 04h)
6.5.1 DIGITAL INTERFACE FORMAT (DIFX)
Default = 01
Function:
These bits select the digital interface format used for the CODEC Serial Port and Serial Audio Interface
Port when not in One-Line Mode. The required relationship between the Left/Right clock, serial clock,
and serial data is defined by the Digital Interface Format and the options are detailed in
11 - 12 .
6.5.2 ADC ONE_LINE MODE (ADC_OLX)
Default = 00
Function:
These bits select which mode the ADC will use. By default, One-Line Mode is disabled, but it can be
selected using these bits. Please see Figures
13 and 14 to see the format of One-Line Mode 1 and
One-Line Mode 2.
6.5.3 DAC ONE_LINE MODE (DAC_OLX)
Default = 00
Function:
These bits select which mode the DAC will use. By default, One-Line Mode is disabled, but it can be
selected using these bits. Please see Figures
13 and 14 to see the format of One-Line Mode 1 and
One-Line Mode 2.
7 6 5 4 3 2 1 0
DIF1 DIF0 ADC_OL1 ADC_OL0 DAC_OL1 DAC_OL0 SAI_RJ16 CODEC_RJ16
DIF1 DIF0 Description Format Figure
0 0 Left-Justified, up to 24-bit data 0 11
0 1 I²S, up to 24-bit data 1 10
1 0 Right-Justified, 16-bit or 24-bit data 2 12
1 1 Reserved - -
Table 7. Digital Interface Formats
ADC_OL1 ADC_OL0 Description Format Figure
0 0 DIF: take the DIF setting from reg04h[7:6] - -
0 1 One-Line #1 3 13
1 0 One-Line #2 4 14
1 1 Reserved - -
Table 8. ADC One-Line Mode
DAC_OL1 DAC_OL0 Description Format Figure
0 0 DIF: take the DIF setting from reg04h[7:6] - -
0 1 One-Line #1 3 13
1 0 One-Line #2 4 14
1 1 Reserved - -
Table 9. DAC One-Line Mode
