Cirrus Logic CS42528 - Manual (Page 43)

DS586F2 43
CS42528
1Eh RCVR Mode
Ctrl SP_SYNC Reserved DE-EMPH1 DE-EMPH0 INT1 INT0 HOLD1 HOLD0
page 61
default
0 0 0 0 0 0 0 0
1Fh RCVR Mode
Ctrl 2 Reserved TMUX2 TMUX1 TMUX0 Reserved RMUX2 RMUX1 RMUX0
page 63
default
0 0 0 0 0 0 0 0
20h Interrupt
Status UNLOCK Reserved QCH DETC DETU Reserved OverFlow RERR
page 63
default
X X X X X X X X
21h Interrupt
Mask UNLOCKM Reserved QCHM DETCM DETUM Reserved OverFlowM RERRM
page 64
default
0 0 0 0 0 0 0 0
22h Interrupt
Mode MSB UNLOCK1 Reserved QCH1 DETC1 DETU1 Reserved OF1 RERR1
page 65
default
0 0 0 0 0 0 0 0
23h Interrupt
Mode LSB UNLOCK0 Reserved QCH0 DETC0 DETU0 Reserved OF0 RERR0
page 65
default
0 0 0 0 0 0 0 0
24h Buffer Ctrl LOCKM1 LOCKM0 Reserved Reserved Reserved BSEL CAM CHS
page 65
default
0 1 0 0 0 0 0 0
25h RCVR CS
Data. AUX3 AUX2 AUX1 AUX0 PRO AUDIO COPY ORIG
page 66 .
default
0 0 0 0 0 0 0 0
26h RCVR
Errors Reserved QCRC CCRC UNLOCK V CONF BIP PAR
page 67
default
0 0 0 0 0 0 0 0
27h RCVR
Errors Mask Reserved QCRCM CCRCM UNLOCKM VM CONFM BIPM PARM
page 68
default
0 0 0 0 0 0 0 0
28h
MUTEC
Reserved Reserved MCPolarity M_AOUTA1 M_AOUTB1 M_AOUTA2
M_AOUTB2
M_AOUTA3
M_AOUTB3
M_AOUTA4
M_AOUTB4
page 69
default
0 0 0 1 1 1 1 1
29h RXP7/GPO
7 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 0 0 0 0 0 0
2Ah RXP6/GPO
6 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 0 0 0 0 0 0
2Bh
RXP5/GPO
5
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 0 0 0 0 0 0
2Ch RXP4/GPO
4 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 0 0 0 0 0 0
Addr Function 7 6 5 4 3 2 1 0
