9
WIKA operating instructions precision pressure transmitter model P-3x
11473500.04 10/2011 GB/D/F/E
GB
3. Specifications
3.1 Measuring ranges
Relative pressure
bar
0 ... 0.25
0 ... 0.4
0 ... 0.6
0 ... 1
0 ... 1.6
0 ... 2.5
0 ... 4
0 ... 6
0 ... 10
0 ... 16
0 ... 25
0 ... 40
0 ... 60
0 ... 100
0 ... 160
0 ... 250
0 ... 400
0 ... 600
0 ... 1,000
psi
0 ... 5
0 ... 10
0 ... 15
0 ... 25
0 ... 30
0 ... 50
0 ... 60
0 ... 100
0 ... 160
0 ... 200
0 ... 250
0 ... 300
0 ... 400
0 ... 500
0 ... 600
0 ... 750
0 ... 800
0 ... 1,000
1)
0 ... 1,500
0 ... 2,000
0 ... 3,000
0 ... 5,000
0 ... 10,000
Absolute pressure
bar
0 ... 0.25
0 ... 0.4
0 ... 0.6
0 ... 1
0 ... 1.6
0 ... 2.5
0 ... 4
0 ... 6
0 ... 160
0 ... 200
psi
0 ... 5
0 ... 10
0 ... 15
0 ... 25
0 ... 30
0 ... 50
0 ... 60
0 ... 100
0 ... 160
0 ... 200
Vacuum and +/- measuring range
bar
-1 ... 0
-1 ... 0.6
-1 ... 1.5
-1 ... 3
-1 ... 5
-1 ... 9
-1 ... 15
psi
-30 inHG ... 0
-30 inHG ... 15 -30 inHG ... 30 -30 inHG ... 60 -30 inHG ... 100 -30 inHG ... 160 -30 inHG ... 200
1) Applies only to P-30
Overpressure limit
■
3 times:
up to 16 bar
■
2 times:
from 16 bar
■
1.5 times: 0 ... 1,000 psi, 0 ... 1,500 psi, 0 ... 10,000 psi
Vacuum resistance: yes
