17 WIKA operating instructions precision pressure transmitter model P-3x
11473500.04 10/2011 GB/D/F/E
GB
6. Commissioning, operation
5. Select a conductor with an outer diameter matched to the angle housing's cable gland. Slide the
cable through the cable gland (2), ring (3), sealing (4) and angle housing (5).
6. Connect the cable ends to the appropriate connection terminals on the terminal block (6) (see table
"Connection diagrams").
7. Press the angle housing (5) onto the terminal block (6).
8. Tighten the cable gland (2) around the cable. Make sure that the sealings are not damaged and that
the cable gland and sealings are assembled correctly in order to ensure ingress protection.
9. Place the flat, square gasket over the pressure transmitter's connection pins.
10. Slide the terminal block (6) onto the pressure transmitter's connection pins.
11. Secure the angle housing (5) and terminal block (6) to the pressure transmitter with the screw (1).
6.2 Making the electrical connection
■ The instrument must be earthed via the process connection.
■ Select a cable diameter that matches the cable gland of the connector. Make sure that the cable
gland of the mounted connector has a tight fit and that the sealings are present and undamaged.
Tighten the threaded connection and check that the seal is correctly seated, in order to ensure a
tight seal.
■ For cable outlets, make sure that no moisture enters at the cable end.
